UCF316-SNR Four Bolt Flange Bearing Unit

UCF316-SNR Four Bolt Flange Bearing Unit

Grey cast housing, radial insert ball bearing with socket set screws,seal with slinger

PRODUCT DEFINITION
Brand SNR
A - Housing height 68 mm
A1 - Housing foot height / flange height 27 mm
A2 - Total height from mounting surface 90 mm
B - Width of Inner Ring 86 mm
d - Shaft diameter 80 mm
e - Distance mounting surface to bearing center 38 mm
G - Grease fitting M10x1
J - Mounting holes distance 196 mm
L - Housing width / diameter 250 mm
N - Mounting hole dimension 31 mm
S - Distance front side/bearing centre 34 mm
