M-UCP207D1-NTN Pillow Block Unit

M-UCP207D1 - NTN
Grey cast housing, radial insert ball bearing with socket set screws,seal with slinger.
Self aligning bearing units with different fixing options and housings made of cast, stainless steel or plastic.

PRODUCT DEFINITION
Brand NTN
A - Housing width 48 mm
Insert IR width (B) 42,9 mm
Bore dia. (shaft diameter) 35
h - Bearing center height 47,6 mm
H1 - Housing foot height 18 mm
H2 - Housing height 93 mm
Distance of attachment bolt holes (J) 127 mm
L - Housing length 167 mm
L1 - Housing foot length 54 mm
u - Mounting hole (width) 17 mm
N1 - Mounting hole length 20 mm
Distance IR face - middle of bearing raceway (S) 17,5 mm
Mounting bolt size (-) 14 mm
