UCFCE208-SNR Bearing Unit

UCFCE208 - SNR

Grey cast housing, radial insert ball bearing with socket set screws,seal with slinger
Self aligning bearing units with different fixing options and housings made of cast, stainless steel or plastic.

This kit contains the following reference(s)
UC208G2
FCE208

PRODUCT DEFINITION
Brand SNR
A - Housing height 23 mm
A1 - Housing foot height / flange height 11,5 mm
A2 - Total height from mounting surface 29,2 mm
A3 - Centering depth / chamfer dimension 2 mm
B - Width of Inner Ring 49,2 mm
d - Shaft diameter 40 mm
e - Distance mounting surface to bearing center -1 mm
G - Grease fitting M6x1
H3 - Centering dia 100 mm
J - Mounting holes distance 120 mm
L - Housing width / diameter 145 mm
N - Mounting hole dimension 11,5 mm
S - Distance front side/bearing centre 19 mm
